Steel and Stainless Steel Reamed Knurled Control Knobs Without Set Screw, Inch
| Steel P/N | Stainless P/N | Reamed Dia | Knob Dia (A) | Total Length (B) | Hub Dia (C) | Knurled Width (D) | Reamed Depth (E) | Ship Wt (lbs) |
|---|---|---|---|---|---|---|---|---|
| SCK-041 | WHR-041 | 3/16 | 3/4 | 5/8 | 1/2 | 1/4 | 3/8 | 0.04 |
| SCK-042 | WHR-042 | 1/4 | 3/4 | 5/8 | 1/2 | 1/4 | 3/8 | 0.04 |
| SCK-043 | WHR-043 | 1/4 | 1 | 3/4 | 5/8 | 1/4 | 1/2 | 0.08 |
| SCK-044 | WHR-044 | 5/16 | 1 | 3/4 | 5/8 | 1/4 | 1/2 | 0.08 |
| SCK-045 | WHR-045 | 5/16 | 1 1/2 | 1 | 3/4 | 5/16 | 5/8 | 0.20 |
| SCK-046 | WHR-046 | 3/8 | 1 1/2 | 1 | 3/4 | 5/16 | 5/8 | 0.20 |
| SCK-047 | WHR-047 | 3/8 | 2 | 1 1/8 | 1 | 3/8 | 5/8 | 0.46 |
| SCK-048 | WHR-048 | 1/2 | 2 | 1 1/8 | 1 | 3/8 | 5/8 | 0.46 |
| SCK-049 | WHR-049 | 1/2 | 2 1/2 | 1 1/2 | 1 1/2 | 9/16 | 3/4 | 1.16 |
| SCK-051 | WHR-051 | 5/8 | 2 1/2 | 1 1/2 | 1 1/2 | 9/16 | 3/4 | 1.16 |
| SCK-052 | WHR-052 | 5/8 | 3 | 1 3/4 | 1 3/4 | 5/8 | 1 | 1.96 |
| SCK-053 | WHR-053 | 3/4 | 3 | 1 3/4 | 1 3/4 | 5/8 | 1 | 1.96 |
