- Steel, Stainless Steel, NiPlated Brass
- Nylon Base
- Stud Style
- Inch
| Steel P/N | Stainless P/N | NiPlated Brass P/N | Thread (A) | Base Dia (B) | Thread Length (C) | Total Height (D) | Max Load (lbs) | Hex Size (E) | Ship Wt (lbs) |
|---|---|---|---|---|---|---|---|---|---|
| BNYLB63 | BSNYLB63 | BRNYLB63 | 1/2-13 | 2 3/8 | 3 | 4 7/8 | 3000 | 1 | 0.52 |
| BNYLB66 | BSNYLB66 | BRNYLB66 | 1/2-13 | 2 3/8 | 6 | 7 7/8 | 3000 | 1 | 0.64 |
| BNYLC63 | BSNYLC63 | BRNYLC63 | 5/8-11 | 2 3/8 | 3 | 4 7/8 | 3500 | 1 | 0.68 |
| BNYLC66 | BSNYLC66 | BRNYLC66 | 5/8-11 | 2 3/8 | 6 | 7 7/8 | 3500 | 1 | 0.80 |
| BNYLD63 | BSNYLD63 | BRNYLD63 | 3/4-10 | 2 3/8 | 3 | 4 7/8 | 3500 | 1 | 0.90 |
| BNYLD66 | BSNYLD66 | BRNYLD66 | 3/4-10 | 2 3/8 | 6 | 7 7/8 | 3500 | 1 | 1.01 |
