- Glass-reinforced nylon body
- Brass threaded insert
- Round
- Metric
| S&W P/N | Thread (A) | O.D. (B) | Tube Guage Shape | Tube Outside Dia | Tube Wall | Static Load (lbs) | Ship Wt (lbs) |
|---|---|---|---|---|---|---|---|
| TE1-1MA | M10 | 1.5 dia | 16 ga. round | 1.5 dia. | .065 | 1500 | 0.22 |
| TE1-1MB | M12 | 1.5 dia | 16 ga. round | 1.5 dia. | .065 | 1500 | 0.22 |
| TE1-1MC | M16 | 1.5 dia | 16 ga. round | 1.5 dia. | .065 | 1500 | 0.22 |
| TE1-1MD | M20 | 1.5 dia | 16 ga. round | 1.5 dia. | .065 | 1500 | 0.22 |
| TE1-10MA | M10 | 2.0 dia | 2.0″ Sch 10 pipe | 1.9 dia. | .109 | 2000 | 0.30 |
| TE1-10MB | M12 | 2.0 dia | 2.0″ Sch 10 pipe | 1.9 dia. | .109 | 2000 | 0.30 |
| TE1-10MC | M16 | 2.0 dia | 2.0″ Sch 10 pipe | 1.9 dia. | .109 | 2000 | 0.30 |
| TE1-10MD | M20 | 2.0 dia | 2.0″ Sch 10 pipe | 1.9 dia. | .109 | 2000 | 0.30 |
| TE2-2MA | M10 | 2.0 dia | 16 ga. round | 2.0 dia. | .065 | 2000 | 0.30 |
| TE2-2MB | M12 | 2.0 dia | 16 ga. round | 2.0 dia. | .065 | 2000 | 0.30 |
| TE2-2MC | M16 | 2.0 dia | 16 ga. round | 2.0 dia. | .065 | 2000 | 0.30 |
| TE2-2MD | M20 | 2.0 dia | 16 ga. round | 2.0 dia. | .065 | 2000 | 0.30 |
